Built-In Web Server
The WebRelay Wireless can operate as a standalone device, allowing it to be controlled and monitored through a standard web browser. Setup and configuration are straightforward, using simple menus and drop-down lists.
Wireless Access Point
The WebRelay Wireless can operate as a self-contained wireless access point, with no additional server or ControlByWeb device required. In this mode, users can view live, real-time temperature readings or input status directly through a web browser or the CBW Mobile app (optional).
Setup is simple, with no app download, subscription, software or programming required.
Logging
Record information such as sensor readings and changes in I/O state. Both periodic and event-based logging are supported.
Email/Text Notifications
Receive notifications based on sensor data and changes in I/O state, helping you stay informed when monitored conditions change.
Peer-to-Peer (P2P) Communication
The WebRelay Wireless can remotely control relays located on other ControlByWeb devices, providing convenient control across connected devices.
- Built-in high current relay
- Optically-isolated digital input
- Up to 4 temperature sensors
- Wireless Wi-Fi 802.11 b/g/n
- Antenna included
- Transmission range up to 250ft
- Logging of the input, counter, temperature, humidity, relay state, and Vin
- BASIC script support for advanced flexibility
- Customizable web-based Control Page
- Send email alerts (up to 8 email addresses) based on user-defined conditions
- Supports encrypted email servers, such as Gmail
- Static or DHCP IP address configuration
- Real-Time clock with NTP server synchronization
- Automatic daylight savings and leap year adjustment
- No software required
- XML, Modbus/TCP and Remote Services
- Field updatable
- Removable terminal connectors for easy installation
- Rugged DIN-Rail/wall-mountable enclosure
- 5-Year Warranty
