Built-In Web Server

The X-410 has a built-in web server, allowing it to be set up, controlled and monitored using a standard web browser or our smartphone app.

Built-in I/O

4 Relays

1A | 28VAC, 24VDC

Independently control low-voltage lights, motors, locks, solid-state relays connected to larger loads and more.

4 Digital Inputs

Non-Isolated Opto-Coupler | 4-26VDC

Monitor on/off states or configure inputs for digital counters or frequency measurement. Suitable for monitoring switches, alarm sensors, level sensors, flow sensors and much more.

Up to 16 Temperature/Humidity Sensors

1-Wire Bus

Monitor up to 16 1-Wire sensors, including temperature and humidity sensors (not included).

Control and Monitor up to 100 I/O

The X-410 supports peer-to-peer communication between ControlByWeb modules. It can communicate with up to 32 modules and allows you to control and monitor up to 100 I/O points.

The X-410 can communicate with all ControlByWeb devices*. It also provides instantaneous messaging between X-400 Series products, allowing the X-410 to control and monitor I/O on other X-400 Series products as though they were directly connected to the module.

Task Builder

The X-410’s built-in interface allows you to create custom “Tasks” for simple and advanced control logic.

Create tasks based on time, input or output status, or device responsiveness. Each task can include up to three actions, providing a flexible control and monitoring solution for your application.

Create up to 50 Scheduled, 50 Conditional, 16 Auto Reboot Tasks, and 20 Override Schedules.

Other Advanced Features

The X-410 also includes advanced features such as the ability to initiate connections to remote servers, BASIC programming, admin/manager/user permissions and more.
